Specifikationer
Generelt
Sokkel
LGA 1700
Formfaktor
M-ATX
Chipsæt
H610 (Intel 12+13th. gen)
Kompatible processorer
12th Gen Intel® Core™ Processors, Pentium® Gold and Celeron® Processors
WiFi
Nej
Antal RAM slots
2
RAM Teknologi
DDR4
RAM
Ram Bus Clock
3200(MAX) / 3000 / 2933 / 2800 / 2666 / 2400 / 2133 MHz
Maks. RAM kapacitet
64 GB
Interface
Ekspansionsåbninger
1x PCIe x16 slot (From CPU)
1x PCIe x1 slot
1x M.2 slot with E-key for PCIe WiFi module only (M2_ WIFI1)
1x PCIe x1 slot
1x M.2 slot with E-key for PCIe WiFi module only (M2_ WIFI1)
Grænseflade (lagring)
1x M.2 slot (Key M, from chipset)
4x SATA 6Gb/s ports
4x SATA 6Gb/s ports
Interne interfaces
1x Front panel audio connector
2x System panel connectors
1x Chassis Intrusion connector
1x TPM module connector
1x 4-pin CPU fan connector
1x 4-pin system fan connector
2x System panel connectors
1x Chassis Intrusion connector
1x TPM module connector
1x 4-pin CPU fan connector
1x 4-pin system fan connector
Interface
1 x HDMI
1 x VGA
1 x Keyboard/Mouse
2 x USB 3.2 Gen 1 5Gbps Type-A
1 x LAN port
3 x Audio connector
4 x USB 2.0
1 x VGA
1 x Keyboard/Mouse
2 x USB 3.2 Gen 1 5Gbps Type-A
1 x LAN port
3 x Audio connector
4 x USB 2.0
Strømkontakter
1x 24-pin ATX main power connector
1x 8-pin ATX 12V power connector
1x 8-pin ATX 12V power connector
Misc.
Dybde
202
Bredde
236
Tilbehør
M.2 clip
2 x SATA Cables
Quick Install Guide
1 x I/O Shield
Driver DVD
MSI Case Badge
Product Registration Card
2 x SATA Cables
Quick Install Guide
1 x I/O Shield
Driver DVD
MSI Case Badge
Product Registration Card
